High Performance X-Ray Machine

With the rapid development of food industries, quality control increasingly stringent, rely on our core technology R&D capabilities, Weighlin have developed and released a variety of online dynamic automatic X-ray inspecting machine suitable for various small or big package or bulk material;

MESSAGE US

VIDEO OVERVIEW KEY FEATURES SPECIFICATIONS LAYOUT OTHER

With the rapid development of various industries, quality control increasingly stringent, rely on our core technology R&D capabilities, Weighlin have developed and released a variety of online dynamic automatic X-ray inspecting machine suitable for various small or big package or bulk material;

X-Ray series of inspection machine is based on the latest X ray imaging and image processing technology developed. It is a new generation machine which meets the European standard completely.

Widely used in food, pharmaceutical, chemical industry, metal and non-metallic foreign body detection. Not only can the various foreign sensitive identification products, such as metal, glass, ceramic, stone, bone, hard rubber, hard plastic, and can provide excellent product integrity detection, identification of product defects, defect etc..

Detecting Method:

X-ray will irradiate the product to be detected and get the transmission image, then by using the image processing technology to judge whether there are foreign bodies in the image.

Detecting Range:

No application limited for the product type, package, packing material. It can inspect the plastic package, aluminum package, glass can, metallic can, bulk material etc.

Foreign items range:

High density materials including metal and non-metal (stainless steel, ferrous, ceramic, stone, bone, hard plastic, hard ceramic, etc). The exact information can be given based on the products to be detected.

Advantages:

A- Full-range Inspection: a full-range inspection of foreign bodies including metal, non-metal; Don’t confine to product attributes, it can detect metallic package, non-metal package, can, etc.

B- High Sensitivity: it can reach the sensitivity as follows:SUS304 ball 0.3*0.3*0.3mm

SUS wire0.2*2mm Glass Ball1.0 mm Ceramic 1.0 mm

C-Easy to Operation: full-color TFT 15" Touch Screen, making it easier to human-machine interaction; Auto-learning function, dispense with manual setting, making it easier to operate. Auto-saving the product image, making it easier to analysis and keep track of the image later.

D- Auto-shielding Function: according to the detecting requirement, it can shield the low sensitivity area and improve the sensitivity as a whole. For example, it can shield the aluminum parts of the ham and detect the rest part. At this time, the aluminum parts won’t be regard as foreign bodies and the sensitivity will be high.

E- High Adaption: it is equipped with industrial control air-conditioner, uninfluenced by the external environment and humidity.

F- Safety Protection: X-ray leakage is less than 1microsievert per hour, well meet the America’s FDA standard, European’s CE standard. More, both the software and hardware are equipped with complete safety protection, which can constantly inspect the machine state and avoid the leakage caused by false operation. For example, if the operator opens the door of machine, the X-ray irradiation is stopped immediately.

G- Quality Guarantee: all the main parts such as the X-ray tube, X-ray detector, motor , inverter, etc are imported from the world’s famous brands to ensure the service life of the machine.

H- Certificates: CE, ISO9001. It has good reputation in Europe, North America, Africa, South

Model	WL-TXR-6080SH
X-ray tube	MAX. 80kV, 350W
Conveyor Parameter	Speed	10-25m/min
	Width	600mm
	Max Height	300mm
	Max Load	30kg
Best Inspection Ability	0.4mm(SUS304 ball) 0.2*2mm(SUS304 wire) 1.0mm(glass) 1.0mm(ceramic)
Screen	Full-color TFT 15" Touch Screen
O/S	Windows XP Professional
Connectivity	LAN port, USB port
Product Storage	Max. Storage of the product parameter can reach 1000 kinds
Product Management	Complete product log
Equipment Management	MTBF, MTTR, Error logs, error analysis
Parameter Adjustment	Auto learning/Manual setting
Image Management	Auto image save/print/analyses
Power Supply	220V, AC, 50/60Hz
Body Material	SUS304
Purification	Easy to wash
Cooling method	Air conditioned cooling
Operation Temperature	0-40°C
Operation Humidity	30-90%
X-ray Emissions	< 1 microsievert per hour
X-ray Protection	Removable Protective Curtain

Remarks:

The technical parameter above namely is the result of sensitivity by inspecting only the test sample on the belt. The sensitivity would be affected according to the products being inspected and working condition.
